WTR-C-2 380V Induction Heater for Mounting and Dismounting Bearing

The 380V induction heater used for mounting and dismounting is WTR-C-2 model, which is induction heating for sleeve of the bearings,couplings,bushings,sleeves and other working pieces. Combined of electrical control panel box and induction heating ring. Applied to railway, petroleum machinery, steel, wind power and other industries.

Welcome to buy the wtr-c-2 380v induction heater for mounting and dismounting bearing made in China from our factory. We are one of the first and leading bearing heater manufacturers and suppliers in China. Please be free to enjoy our discount price and good service.

Features

1. Automatic demagnetization: <0.8mT

2. Certifications: CE, ISO9001, EMC,FCC.

3. High efficiency, safe and reliable using process;

4. Type: Portable, car type, center height adjustable well frame.

5. Induction heating ring: oil winding & 12 pieces of the iron cores & aluminum shell.

6. Electrical control panel box: 2 timing modes (minutes and seconds), LCD digital display.

Working Principle

Adopting the electromagnetic induction heating principle to heat the bearing sleeve from outer to inner, making the bearing sleeve expand rapidly, inner size will be larger than the shaft size, thus could dismount or mount the bearing sleeve.

Just control the heating time or temperature when use the WTR bearing induction heater to mount or dismount bearing sleeve, the sleeve will not anneal or deform. Original method (Gas cutting or Hammering) could not guarantee intact of the bearing sleeve. Each bearing inner sleeve is with high cost, saving cost during the bearing inner sleeve changing process is very important for the metallurgy and railway industry, it indirectly increases the enterprise efficiency. Thus WTR bearing induction heater is ideal dismount tool for the enterprises.

Comparison of WTR-C-1 & WTR-C-2

	WTR-C-1	WTR-C-2
Power	42KVA	60KVA
Speed	Around 2 minutes	Around 1.5minutes
Noise level	Lower	Higher
Using life	WTR-C-2 has longer life than WTR-C-1
Operating	WTR-C-1 is easier operating than WTR-C-2
Price	WTR-C-1 is cheaper than WTR-C-2

WTR Bearing Induction Puller Common Used Models

Bearing	Inner Sleeve Size	Frequency	Voltage	Current	Heating Time		Temperature
Models	Outside x Width	(HZ)	Voltage	(A)	Mount	Dismount	⁰C
FC3045120	φ169×120	50	380V	100	100”	120”	120
FC3248124	φ183×124	50	380V	100	100”	120”	120
FC3652168	φ202×168	50	380V	100	100”	120”	120
FC3852168	φ212×168	50	380V	100	100”	120”	120
FC4058192	φ226×192	50	380V	100	110”	120”	120
FC4462192	φ246×192	50	380V	100	110”	120”	120
FC4666206	φ260×206	50	380V	120	120”	130”	120
FC5274220	φ292×220	50	380V	130	120”	130”	120
FC5678220	φ312×220	50	380V	130	120”	130”	120
FC6084240	φ332×240	50	380V	140	120”	130”	120
FC6490240	φ355×240	50	380V	140	120”	130”	120
FC6890250	φ371×250	50	380V	140	120”	130”	120
FCD6896350	φ378×175	50	380V	140	120”	130”	120
FCDP130180650	φ704×325	50	380V	170	15’	16’	130
FCDP146206750	φ809×375	50	380V	180	20’	20’	130
FCDP160216700	φ878×350	50	380V	180	22’	25’	130
Heating time in the form is approximation tested under 28℃,users need to do adjustment according to the Room temperature.

Rely on the excellent product quality and thoughtful professional service, WTR brand bearing induction heater has been appointed as sole supplier by Fortune 500.
